Improvement & Cost

2020 New Ullman Dacron Mainsail $5,000

2020 Replace running rigging (halyards, sheets) $1,200

2020 New Sunflare Solar 1.8 kW Solar PV System $7,900

2020 Dual Valence 48V 21-kWh Propulsion Battery Banks (LiFePO4) $24,000

2020 Dual Valence Supervisory Battery Management Systems $4,200

2020 Dual Victron Quattro Shore Power Charger Inverters $5,000

2020 Dual Victron CCGX Color Displays $1,000

2021 Two electric winches, 2nd one new 2021 $1,650

2021 New 3-burner electric cermaic-top stove $600

2021 New 4-in-1 SS Microwave Oven $400

2021 New, replacement Lewmar Windlass $1,800

2021 Always on wifi router (w/ Verizon sim Card) $200

2021 Lonestar 1-min GPS Asset Tracking System $200

2021 Dual Oceanvolt 15 kW Servoprop Propulsion System $62,000

2021 Dual Valence 12V 6.6-kWh House Battery Systems (LiFePO4) $8,000

2021 Dual Valence House Battery Management Systems $300

2021 Dual Flexifold propellers on Yanmar Diesels $3,600

2021 New bottom paint and prop-speed, 4 propellers $2,200

2021 Eight (8) Victron DC/DC Converters $2,240

2022 New Cockpit & Helm Cushions $2,200

2022 Re-serviced liferaft $1,800

2022 Replaced 6 fire extinguishers $250

2022 New Balmar 48V, 60A alternator & Balmar regulator $4,100

2022 New Magna SS Grill $250

2022 New e-propulsion Spirit electric outboard motor & battery $2,400

2022 New inflatible dinghy $1,000

2022 SS Electric Hot Water Pot $30

2022 Kuerig Coffeemaker $60

2022 10.5 ft rigid SUP with cover $600

TOTAL: $144,180

Featured Equipment

Electric and Diesel propulsion (Oceanvolt & Yanmar)

48V and 12V alternators

Three Inverters (incl. 2 Victron and 1 Magnum)

Dual 21 kWh Propulsion battery packs (Valence LiFePO4)

Dual 6.6 kWh House battery packs (Valence LiFePO4)

Mastervolt Whisper 6 kW diesel generator

Electric Davits

Two Lewmar electric winches

New Lewmar windlass

Recent Maintenance - Oceanvolt,

Replace/re-pack gear grease

Replace ATF gear oil

Replace propeller and sail drive anodes

Paint electric sail drive legs w/ non-copper paint

Recent Maintenance - Yanmar

R&R shaft seals Starboard Sail Drive

Replace gear oil both saildrives

Replace engine oil both engines

Drain fuel filter canisters, replace Racor 30 micron fuel filters

Replace Yanmar engine fuel filters

Replace raw water impeller

Replace Starboard raw water impeller valve

Replace Anodes on Saildrives and Flexifold Propellers

Recent Maintenance - Mastervolt Generator

July 2022 Replace Engine Oil

 Recent Maintenance - Misc.

May 2022 Oiled steering cable system/greased pulley bearings

Oct 2022 Repaired Raymarine Radar + New Comm Cable

Electronics

Raymarine 12" Hybrid-touch chartplotter

Raymarine Autopilot & instruments

Raymarine Radar

Victron CCGX Color displays

Eight (8) Victron DC/DC Converters

Known issues

AIS system receives but does not transmit

Due for bottom paint

Air Conditioning systems should be serviced.

• Interior saloon blinds - front & side windows

• Fusion 700i Series Marine Stereo in saloon with docking station. Includes Bluetooth, USB, & AUX connectivity. Fusion Marine speakers in saloon (2) & aft cockpit (2). Wired remote control at helm station (1) - Note: Raymarine MDFs (not included in option) & personal wireless devices (only if connected wirelessly to Raymarine MFD via the Raymarine APP) can control system.

• Raymarine Base Pack: Includes Ray55 VHF (US-CARIB) at Switch-panel & additional VHF handset at helm. p70 color autopilot display, a95 9" Multifunction display with WiFi and i70 Color instrument at Helm-station. With retractable depth & speed, plus wind transducers.

• Additional i70 Display at Helmstation (Reguires Base Pack) a

• a125 12" Multifunction display with WiFi at helm station in lieu of a95 Multifunction display

• HD Color Radar includes 4 kW 18" 48nm Radome scanner, c/w mast bracket and genoa protection.

• Raymarine Automatic Identification System with AIS 650 Transceiver.

• 110v Shore Power Pack: includes 2 heavy duty 50ft 30amp shore power-lines, AC switch panel, AC outlets in cabins, galley, at freezer & switch panel

• Shaver outlets in heads, 110 volt with GFI protection (2) (only for boats with 110 volt systems

• Inverter/Battery Charger: 12V- 110V/2.0 kW inverter with 100A change rate, including remote operation panel with battery monitor (only for boats with 110v systems,

• Upgrade std Lead Acid house and engine batteries to AGM batteries One additional AGM house battery (210 amp hr) - House battery note: A maximum of one additional house battery can be added on the L40; i.e. max three house batteries in total

• Ventilation fans in saloon (2) & cabins (3) for Three Cabin Layout - (5) total Double USB socket in cabins - 3 Cabin layout

• Windlass "up" footswitch

• Air conditioning System (2) 16.000 BTU 110v

• Genset - Mastervolt supplied from aft fuel tank

• Winch: 2 - Electric Sheet winch (in lieu of outboard primary winch)

• Provision for TV in Saloon - Swing Bracket & AC Outlet

• Electric flushing toilets: Jabsco quiet flush (seawater option) in lieu of standard toilets (2)

• LPG gas outlet on stern rail for optional BBQ

• Aft cockpit side and back shade curtains only

• Custom stainless steel davit system with tackle complete with electric winch

• Stackpack as per exterior pack choice

• Bowsprit complete for roller furler and Code 0

• Square Top mainsail in lieu of standard main

• 45lb (20kg) Delta anchor complete with 165ft (50m) chain

• Anchor bridle, shackles and hook

• Fenders (6), mooring lines (4,16mm x 10m), spring lines (2,16mm x 15m)

Leopard Catamarans excitedly announces the new Leopard 40. This innovative and performance driven Leopard 40 is sure to excite anyone interested in a new catamaran in the 40 ft range.

The Leopard 40, like other Leopard models before her, is a product of South African boat builders Robertson and Caine and includes a unique, modern design thanks to experienced naval architects Simonis and Voogd as well as Robertson and Caine's design team. She resembles her predecessors in speed, agility, and blue-water performance, but her enhancements include an increased volume in the hulls and a design consistent with the rest of the Leopard range currently in production.

The Leopard 40’s interior design is unlike any Leopard before her. Her galley is located forward and the forward-facing settee and table are now located aft. This allows for a panoramic view with large sliding glass doors between the saloon and the aft cockpit. This arrangement promotes easy communication for guests and an open flow between the saloon and the aft cockpit, and a fusion of indoor and outdoor living space. In addition, the galley area includes a large forward-facing window and an access door to the forward platform of the boat. The access door enhances the open concept feel and easy navigation in and around the yacht. It also promotes ventilation throughout the interior.

Like the rest of the Leopard line, the new Leopard 40 includes a light blonde interior with a light, modern and airy feel.
